It is suitable for heating and solidification, drying and dehydration of raw materials in
pharmaceutical industry, chemical industry, foodstuff industry, agricultural and sideline
products, aquatic products, light industry, heavy industry and so on. The raw materials can
be medicine raw materials, Chinese traditional medicine,tablet of drink, immersed electuary,
powder, granule, packing bottle, pigment, dyestuff, dehydration vegetable, dried fruit and
melons, banger, plastic resin, electric elements, drying varnish and so on.
1.The heat source can be steam, electricity, far infrared, or steam+electricity.
Customer can select one of the heating ways in accordance with practical
conditions.
2.Temperature of operation:50-140℃ for steam, Maximum temperature will be
150℃.
3.50-500℃for electricity or far infrared.
4.There are automatic and computer control systems for customer selection.
5.The normal pressure of steam will be 0.02-0.8Mpa(0.2-8kg/cm ) 2
6.The equipped power of electric heater will be 15kw Calculated with Model I and
the opera-tional power to be used will be 5-8kw/hr.
7.For special requirement, please indicate it in order.
8.The price of non-standard oven shall be discussed additionally.
9.If the operation temperature is more than 140℃ or less than 60℃ ,please indicate it in order.
10.The size of drying trolly and tray is standardized. They can be exchanged each
other.
11.The size of drying tray: 460×640×45(mm)
Features
◇Wide application and can be suitable for a variety of materials, is a versatile drying equipment.
◇Most of hot air is circled inside the oven. The hot efficiency is high The energy source can be saved.
◇It uses enhanced ventilation and equips with adjustable air distributing plate inside the oven , Raw material can
be dried evenly , The heat source can be steam ,hot water, electricity of far infrared.
◇ The applied fields are wide and can be suitable for all kinds of raw materials. It is a comprehensive drier.
◇ Temperature application range, according to user requirements, up to room temperature to 350 ℃
◇The machine has low noise and stable operation.The temperature can be controlled automatically. The
installation and maintenance are very convenient.
